Key Features

Exact Force Induction Brake

Exact Force Induction Brake offers instant, smooth, precise step speed changes at the push of a button, and with no moving parts, it's quieter and more durable as well.

Landmarks

Add challenge to your workout by scaling famous buildings, monuments and wonders of the world with our integrated Landmarks program. (XIR/XER: 21 courses; XR: 11 courses).

Industry-leading Safety

Our suite of safeguards includes an infrared sensor, auto-pause control zone, reversible steps and emergency stop buttons for the most secure stair-climbing experience on the market.

Convenience Features

Includes water bottle holder, heart rate grips and conveniently positioned handlebar controls to pause, stop or adjust your resistance at a moment's notice.

Compact Design

Specifically designed for home use, our ClimbMill fits comfortably in workout spaces with ceilings lower than traditional fitness facilities.

Step Positioning Sensor

Our step positioning sensor locks the bottom step at the lowest possible point, making it easier than ever to start your workout and step off when you're done.

Sweat Management System

Our exclusive Sweat Management System tracks sweat away from the ClimbMill's critical components, prolonging the life of the equipment.

Specifications

Console

Display Type	8.5" Extra-wide blue LCD (22 cm)
WiFi Enabled	ViaFit Connectivity
Bluetooth Enabled	No
USB Port	Internal USB port for software updates
Speakers	No
Console Apps	No
Virtual Active Integrated	No
Passport Ready	Yes
ViaFit Connectivity	Yes
Heart Rate	Wireless heart rate, Polar compatible
Console Extras	Integrated reading rack, energy saver mode
Workout Programs	5 Total — Manual, Fat Burn, Intervals, Landmarks, Target HR
Workout Feedback	Time Elapsed, Time Remaining, Calories, Watts, SPM, Steps, Heart Rate, METS, Resistance, Floors

Frame

Frame Type	ClimbMill
Step Depth	23 cm / 9"
Step-on Height	26.7 cm / 10.5"
Step Height	14.3 cm / 5.6"
Step Width	40.2 cm / 15.8"
Resistance System	Exact Force Induction Brake
Resistance Range	25 levels, electronically adjustable
Delineated Steps	Yes
Steps Per Minute	24–137 SPM
Handle Bar Type	Multi-position, stationary with resistance / pause & stop toggles and heart rate grips
Extras	Water bottle holder

Tech Specs

Assembled Dimensions (L x W x H)	135 x 72 x 191 cm / 53" x 28" x 75"
Assembled Weight	134.5 kg / 296 lbs.
User Weight Range	Minimum: 45 kg / 99 lbs. Maximum: 136 kg / 300 lbs.
Electrical Requirements	120V AC power, 15A circuit (voltage may vary outside the USA)
Power Supply	NEMA 5-15 Power cord (requirement may vary outside the USA)
